Types and uses of metal filter screens

Metal filter is also called filter metal mesh, metal mesh bag filter, metal mesh filter.

Metal filters are classified by weaving:

1. Plain weave.

2. Twill weave.

3. Ordinary Dutch weaving.

4. Twill Dutch weave.

5. Pad type ciphertext weaving.

Metal filter material classification: SUS201, SUS304, SUS304A, SUS316, SUS316L, SUS321, SUS310S, duplex (2205, 2207), 904L (super stainless steel), ferrite, martensite, austenite, nickel-chromium alloy, Copper-nickel alloy, gold wire, silver wire and other special alloy raw materials (processed as required).

Metal filter plain weave (also called crimped organization) mesh size 10cm-0.0335mm (mesh 0.20 mesh-400 mesh)

The metal filter mesh size is 2.0mm-0.02mm (2 micron filter value) 12 mesh-635 mesh.

Metal filter mesh weaving (also known as mat weaving) mesh size 1.8mm-0.002mm (filter value is 2 microns) 12 mesh × 64 mesh-325 mesh × 2300 mesh-400 mesh × 2800 mesh-435 × 3500 mesh is the most dense ( The filtration accuracy can reach 2 microns).

Metal filter width: 1 meter, 1.22 meters (48 inches), 1.3 meters, 1.524 meters (60 inches), 1.6 meters, 1.8 meters, 2 meters, 2.5 meters, 3 meters wide screen, our company has stock sales. The width of 3-8 meters needs to be customized.

Performance: Acid resistance, alkali resistance, high temperature resistance, strong tensile force, and wear resistance.

use:

1. Used for screening and filtering under acid-base environmental conditions, as a mud mesh in the petroleum industry, as a screen filter in the chemical fiber industry, and as a pickling mesh in the electroplating industry.

2. Used in mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries.

3. Used in air conditioners, purifiers, range hoods, air filters, dehumidifiers, dust collectors, etc., suitable for various filtration, dust removal and separation requirements.
