Introduction:
The egg grading machine is very fit for egg processing factory, poultry eggs farming market or egg producing company. This eggs sorting machine is suitable for various kinds of eggs like chicken eggs, duck eggs, goose eggs or any other eggs.
Here's how the egg grading machine works:
1.The workers can load the eggs onto the conveying and sequence collating belt manually or by vacuum egg lifter(optical).
2.The conveying belt and sequence collating belt will transport all the eggs into the egg candling booth.here all the eggs will be checked by the transmitted light
then experienced workers can select out the damaged eggs.
3.The rollers on the egg grading machine will transport all the eggs onto the mechanical egg weighing scale.here the system will weigh all the eggs.
4.Eggs of different weight will fall onto different lanes on the egg collecting belt,thus,workers should collect eggs from different lanes onto different egg trays.
Features:
1.Humanized design, low operating costs, high adaptability.
2.Adopt professional design, strengthening all the parts, rich durability.
3. Automatic control, saving labor, high accuracy stable movement.
4. Easy to operate and maintain, reliable quality and service.
5. Accurate grading, zero breakage rate.
6. Wide application and reliable performance, high efficiency and low energy saving.
7.The material of stainless steel material,corrosion resistant.
8. Small grader, smart and convenient for different levels of egg processing enterprises.
9. Different models with different capacity and material for choose.
Specifications:
QunKun main capacity egg grading machine available
| NO. | Item | Specification | |
| 1 | QK-JD01 Egg grading machine | Type | QK-JD01 |
| Capacity | 4000pcs/h | ||
| Material | Carbon steel,stainless steel | ||
| Precision | ±0.5g | ||
| Grade | 7 | ||
| Power | 200W | ||
| Voltage | 220V | ||
| L x W x H | 1438 x 1320 x 980(mm) | ||
| Net weight | 160KG | ||
| Gross weight | 200KG | ||
| Function | Grading eggs by weight | ||
| 2 | QK-JD02 Egg grading machine | Model | QK-JD02 |
| Capacity | 5400 pcs/h | ||
| Material | Carbon steel,stainless steel | ||
| Precision | ±0.5g | ||
| Grade | 5 | ||
| Power | 200W | ||
| Voltage | 220V | ||
| L x W x H | 1820 x 1620 x 1050(mm) | ||
| Gross Weight | 260KG | ||
| Net Weight | 190KG | ||
| Function | Grading eggs by weight |
Note: Special size and specifications can be made according to customers requires.
Technology:
1.The frame structure is made of 304 stainless steel. The weight of the equipment is light, the strength is good, and the appearance is beautiful.
2.Knife-type conveying, lever weighing principle, accurate weighing, easy adjustment
3.Eccentric sprocket and compensating sprocket drive structure for improved efficiency
4.The cam gear structure and chain drive are used to make the eggs weighed in order without damage.
5.Self-rolling rubber wheel, automatically adjust the arrangement of the eggs
Drawing and Gallery:
Product Name: Egg sorter egg grading machine
