Special Alloy Wire Mesh

Special Alloy Wire Mesh

Home / Products / Special Alloy Wire Mesh
Special Alloy Wire Mesh

The Duplex Stainless Steel Wire Mesh UNS 2304 The Duplex Stainless Steel Wire Mesh UNS 2304 The Duplex Stainless Steel Wire Mesh UNS 2304 (China Brand: 00Cr23Ni4N) is a kind of duplex stainless steel wire mesh with low alloy and developed by Swedish. Its solid solution temperature is around 1000℃. The organization is 40%-50% ferrite and 50%-60% austenite, with common features of duplex stainless steel. American standard is UNS S32304, Swedish trade mark is SAF 2304.

Inquire Now

Duplex Stainless Steel Wire Mesh UNS S31803(S32205) Duplex Stainless Steel Wire Mesh UNS S31803(S32205) Duplex Stainless Steel Wire Mesh UNS S31803(S32205), this wire mesh is made of 21% chromium, 2.5%molybdenum and 4.5% nitrogen nickel alloy. It has high strength, good impact toughness and good overall and partial stress corrosion resistance. In the world it known as 2205, trade mark is SAF2205.

Inquire Now

Super Duplex Stainless Steel Wire Mesh UNS 32750 Super Duplex Stainless Steel Wire Mesh UNS 32750 Super Duplex Stainless Steel Wire Mesh S32750 (F53/SAF2507) alloy is super duplex stainless steel made up of 250%Cr, 40% Mo and 7% Ni and N. This steel is mainly used in chemical, petrochemical and marine equipment which required special in tension and corrosion resistance.

Inquire Now

Dutch Weave Stainless Steel Wire Mesh Dutch Weave Stainless Steel Wire Mesh Dutch weave stainless steel wire mesh is manufactured from stainless steel wire. Different from plain weave woven wire mesh and twill woven wire mesh, the dutch weave woven wire mesh has different diameter in the weft and warp directions. Commonly the warp wire is coarser wire, which can supply the high tensile strength for the wire mesh. The weft wire is finer wire, which can ensure the excellent filtering performance. This unique structure with greater strength and finer openings is primarily used as a filter cloth.

Inquire Now

Plain or Twill Weaved Stainless Steel Wire Mesh Plain or Twill Weaved Stainless Steel Wire Mesh Plain or twill weave stainless steel wire mesh has good performance at acid-resisting, alkali-resisting and anti-corrosion.High strength, good tension\toughness and abrasion performance, durable in use.Resistance to high temperature oxidation, 304 stainless steel wire mesh nominal resistance temperature is 800 degree Celsius, 310S stainless steel wire mesh nominal resistance temperature can reach 1150 degrees Celsius.Room temperature processing, easy to do plastic processing, make the possible use of stainless steel wire mesh diversified.Good surface finish, no need to do any surface treatment, with convenient and simple maintenance.

Inquire Now

Reverse Dutch Weave Stainless Steel Wire Mesh Reverse Dutch Weave Stainless Steel Wire Mesh Reverse dutch woven wire mesh is another product specially designed for filtering. It is mainly made of stainless steel wire, which is chemical resistance, alkali and acid resistance, rust and corrosion resistance. It can ensure the durable filtering performance during the usage. The reverse dutch weave can also be used in brass wire, which is also has chemical stability for filtering.Using two different sizes of wire diameter, the stainless steel wire or brass wire is woven into reverse dutch woven wire mesh. Which is widely used as filter disc or other filtration products in petrochemical, aerospace and other field.

Inquire Now

FeCrAl Wire Mesh FeCrAl Wire Mesh FeCrAl wire mesh is also called FeCrAl alloy wire mesh, heating resistance alloy woven wire, electro thermal alloy mesh. The raw material is woven into a continuous meshes. Except for the FeCrAl woven wire mesh, there are FeCrAl expanded metal mesh and FeCrAl perforated mesh.FeCrAl wire mesh has outstanding heating resistance, oxidation resistance performance. It is mainly used in the industry electric furnace, household appliances. It is an ideal material for heating and drying.

Inquire Now

Brass Wire Mesh Brass Wire Mesh Brass wire mesh has a yellow bright color. Brass is the alloy of copper and zinc. It contains 65% copper and 35% zinc. Brass wire is woven into fine woven meshes or coarse woven meshes. Compared with the red color of copper woven wire mesh, the brass woven wire mesh has yellow colors.The brass wire mesh is also called paper making cloth, which is used in the paper making industry. Paper making cloth uses the phosphor bronze wires in the warp and brass wires in the weft. Brass woven wire cloth has outstanding acid and alkali resistance, so it is widely used for filtering applications.

Inquire Now

Copper Wire Mesh Copper Wire Mesh Copper wire mesh is also called red copper mesh, because of the red color. The purity of copper is 99.8%. The aperture of copper wire mesh can range from 2 meshes to 100 meshes, which can suit for different requirements. Except for the pure copper woven wire mesh, there are copper alloy wire mesh, such as the brass wire mesh and phosphor bronze wire mesh.The copper woven wire mesh is non-magnetic, so it is also called shielding screen in the circuits, laboratories and computer rooms, it also has outstanding wear resistance and sound insulation performance.Copper wire mesh with a red color is commonly used for shielding and filtering.

Inquire Now

Phosphor Bronze Wire Mesh Phosphor Bronze Wire Mesh Phosphorous wire mesh is also a copper-based alloy. It is mainly consist of 85% - 90% copper and 10% - 15% tin. Phosphorous bronze wires is acid and alkali resistance. The phosphorous bronze wire mesh has a beautiful color and fine mesh sizes, so it is commonly used as the window screen in homes and hotels. It can not only prevent insects from entering, it can add the traditional beauty for the house.

Inquire Now

Pure Nickel Wire Mesh Pure Nickel Wire Mesh The nickel is a sliver color metal. According to the purity, the nickel has different material types, such as the N2, N4, N6 and N8. Pure Nickel wire mesh is manufactured from nickel wire with high purity not less than 99%. Nickel woven wire mesh features excellent corrosion, acid and alkali resistance, high electrical conductivity, thermal conductivity and ductility, heat resistance, wear resistance. Nickel wire mesh or low-alloy nickel woven wire mesh is useful in chemical processing because of its resistance to various chemicals including acid, alkali. It is also useful in the electronics due to its high electrical conductivity. The Nickel wire can be also used in the heat exchange due to its thermal conductivity and ductility.

Inquire Now

Monel Wire Mesh Monel Wire Mesh The Monel wire mesh, similar to the inconel wire mesh, it is also a type of woven mesh, which is weaved from nickel-based alloy wire. Monel is the alloy of nickel, copper and other chemical elements. According to different chemical elements, the monel wire mesh has Monel alloy 400 and monel alloy K500 materials.Alloy 400 has outstanding corrosion resistance property in the flowing sea water. It can also resist to stress corrosion cracking. Alloy 400 is the most widely used monel material.Alloy K500 also has outstanding corrosion resistance property like the Monel alloy 400, but the Monel alloy K500 has been added aluminum, which can let the monel K500 offer greater tensile strength and hardness than the Monel alloy 400.The monel wire mesh includes fine woven wire mesh, which has the mesh size larger than 80 meshes, and coarse woven wire mesh with the meshes no larger than 80 meshes.

Inquire Now

Inconel Wire Mesh Inconel Wire Mesh Inconel wire mesh is a type of woven wire mesh made of inconel wires. The inconel is the alloy of nickel, chrome and iron. According to the chemical composition, the inconel can be divided into inconel 600, inconel 601, inconel 625, inconel 718 and inconel X750.Without magnetism, inconel wire mesh can be used in a temperature range from below zero to 1093 degree. Inconel wire mesh has excellent corrosion resistance, and its oxidation resistance performance is better than the nickel wire mesh. It is widely used in the petrochemical, aerospace industry and other fields.

Inquire Now

Nichrome Wire Mesh Nichrome Wire Mesh Nichrome is the alloy of nickel and chrome. According to different chemical composition, nichrome can be divided into Cr20Ni80, Cr15Ni60 and Cr20Ni35.Nichrome wire mesh is made of the nichrome wire. Nichrome wire mesh has outstanding ductility, high tensile strength, oxidation resistance, sulfur resistance and other features.Nichrome wire mesh has a wide range of applications, including the aerospace, shipbuilding, military industry, chemical and other fields.Nichrome wire mesh has outstanding oxidation and sulfur resistance.

Inquire Now

Hastelloy Wire Mesh Hastelloy Wire Mesh Hastelloy wire mesh is another nickel-based alloy wire mesh except for the monel wire mesh and nichrome wire mesh. The hastelloy is the alloy of nickel, molybdenum and chromium. According to the different chemical composition of material, the hastelloy can be divided into hastelloy B, Hastelloy C22, Hastelloy C276 and Hastelloy X.Hastelloy wire mesh is the best corrosion resistant material among all of the metal materials. It is corrosion resistant in the acid, oxidizing, salt and other corrosion environments.

Inquire Now

Silver Wire Mesh Silver Wire Mesh Silver wire mesh is manufactured from pure silver wire. The silver mesh is weaved through plain weave and twill weave into square meshes. Silver woven wire mesh has outstanding electric and heat transfer conductivity. It is better than the nickel wire mesh and any other metal woven wire mesh. Silver wire mesh has a widely application in electronic industry, electric power industry, aerospace and other industries.Silver wire mesh can also be expanded into diamond meshes to form silver expanded metal mesh.

Inquire Now

Titanium Wire Mesh Titanium Wire Mesh Titanium wire mesh is a kind of products with outstanding corrosion resistance, low density and nontoxic performance. In the corrosion environment, the surface of high purity titanium mesh will form an oxidation film layer to protect wire mesh from being corroded. The layer is compact and inert, which has strong resistance to the corrosion. It has excellent corrosion resistant performance in below environment: Seawater, wet chlorine, chlorite and hypochlorite solution, nitric acid, chromic acid, metal chlorides and organic salts.Because of the outstanding corrosion resistance, the titanium woven wire mesh has become the replacement material of nickel-free stainless steel wire mesh, aluminum wire mesh.The titanium wire mesh has expanded wire mesh and perforated wire mesh types, which can be used for different applications.

Inquire Now

Tungsten Wire Mesh Tungsten Wire Mesh Tungsten wire mesh is special due to the metal used. With purity more than 99.9% Tungsten is a greyish white refractory metal, has the highest tensile strength among all metals. The metal has the highest melting point and the lowest vapor pressure. Tungsten is extracted from ores, crushed to become powdery and thereafter mixed and molded to create the wire mesh.

Inquire Now

Molybdenum Wire Mesh Molybdenum Wire Mesh Molybdenum Wire Mesh is made of pure molybdenum wires or alloy wires. Molybdenum wire mesh has heat-conductivity and corrosion resistance.Molybdenum wire mesh has high strength and low elongation, excellent electric-conductivity, heat-conducting property. It can also resist corrosion, acid, alkaline, oxidation and other harsh environment. Molybdenum wire mesh can be popularly used in high-temperature field such as furnace, petroleum, chemical, food, medicine, machinery and other industries for filtering and sieving use.

Inquire Now

Special alloy wire mesh offers a tailored and high-performance solution for demanding applications, combining the strength and corrosion resistance of specialized alloys with the precision of mesh construction. This versatile material finds applications in industries where standard wire meshes fall short, providing superior durability and reliability in challenging environments.

Read More
