FeCrAl Wire Mesh

FeCrAl wire mesh is also called FeCrAl alloy wire mesh, heating resistance alloy woven wire, electro thermal alloy mesh. The raw material is woven into a continuous meshes. Except for the FeCrAl woven wire mesh, there are FeCrAl expanded metal mesh and FeCrAl perforated mesh.

FeCrAl wire mesh has outstanding heating resistance, oxidation resistance performance. It is mainly used in the industry electric furnace, household appliances. It is an ideal material for heating and drying.

Introduction:

Features of FeCrAl Wire Mesh:

FeCrAl wire mesh is also called FeCrAl alloy woven wire mesh, heating resistance alloy woven wire mesh, electro thermal alloy mesh. It has features of Heating resistance; Oxidation resistance; Sulfur resistance; Anti-penetration; High surface load; High electrical resistivity; Long lasting and durable

Applications of FeCrAl Wire Mesh:

The FeCrAl wire mesh is mainly used as the drying and heating equipment in metallurgy, colliery, dyeing, food factory, hospital, high density board factory and so on.

The FeCrAl wire mesh is an ideal heating resistance material in the industry electric furnace, household appliances, gas burners and infrared device.

Features:

1. Heating resistance.

2. Oxidation resistance.

3. Sulfur resistance.

4. Anti-carburizing.

5. High surface load.

6. Long lasting and durable.

7. Low temperature coefficient of resistance.

Specifications:

Mesh	Wire Gauge	Aperture (mm)	Wire Diameter (mm)	Roll Width (m)	Weight (kg/m²)
8 (T)	21	2.375	0.8	1.0	2.5
8 (T)	22	2.475	0.7	1.0	1.84
10 (T)	23	1.94	0.6	0.6	1.69
12 (T)	24	1.557	0.559	1.0	1.8
17 (T)	24	0.94	0.55	0.6	2.57
20 (P)	33	1.02	0.25	1.0	0.587
20 (P)	32	1.0	0.27	1.0	0.685
20 (P)	30	0.97	0.30	1.0	0.846
25 (P)	30	0.71	0.30	1.0	1.125
30 (P)	38	0.69	0.15	1.0	0.30
34 (P)	33	0.49	0.25	1.0	1.06
40 (P)	35	0.425	0.21	1.0	0.83
40 (T)	35	0.425	0.21	1.0	0.83
44 (T)	35	0.367	0.21	1.0	0.88
60 (T)	38	0.273	0.15	1.0	0.66
80 (P)	43	0.227	0.09	1.0	0.324
