Chain Link Fence, also called Cyclone Fence or Diamond Mesh Fence. As a versatile Fence, Chain link Fences are the fastest and most cost effective fence products on the market today. using the woven steel wire to make the panel, it is widely used in everywhere. Due to the different applications, it is available in various wire gauges and mesh sizes. All Linkland Chain Link Fence rolls are completed with line wires and knuckled edges. What’s more, the Chain Link Fence with barbed edges is more popular and has higher security.
Typical applications for Chain Link Fence include boundary, security, high security, and sports, therefore making it suitable for many types of property and use.
The finish of Chain Link Fencing can be galvanised or plastic coated in green or black or any other RAL colors, with either a galvanised or un-galvanised core wire. Posts are made from Round steel pipe (dia 42mm / 48mm / 50mm / 60mm / 75mm). They are usually hot dip galvanised and can be polyester coated to match the colour and finish of the chain link fence as required.
The heights available for Linkland chain link mesh fence range from 900mm to 3.6m. Vertical or cranked post extensions are available for fences above 2.0m to carry barbed wire or razor wire for added security.
Features:
Low Cost effective solution.
Quick and Easy install
high security products
Anti-rust and anti-corrosion.
Suitable where safety is a consideration
Durable and well structured.
Excellent through vision
10-Year limited warranty
Customisation options
Specifications:
Opening
1"
1.5"
2"
2-1/4"
2-3/8"
2-1/2"
2-5/8"
3"
4"
25mm
40mm
50mm
57mm
60mm
64mm
67mm
75mm
100mm
Wire diameter
18Ga - 13Ga
16Ga - 8Ga
18Ga-7Ga
1.2mm- 2.4mm
1.6mm - 4.2mm
2.0mm-5.00mm
Length of the roll
0.50M - 100M(or more)
Width of the roll
0.5M - 5.0M
Surface Treatment
Hot Dipped Galvanized OR Electric Galvanized + Polyester Powder Coated (All colors in RAL)
Materials and specifications can be made according to customer detailed requirements.
Note: Special size and specifications can be made according to customers requires.
Technology:
We can supply different type of Chain Link Fence gate according to your request. We could design the gate for you for free. Accessories
Coating
The Chain Link Fence are manufactured using galvanized steel wire with super-durable powder coating assures a long service life for the fence system.Our powder coating material is the top brand like AkzoNobel, which provides the industry's Highest Weather- rability and Gloss Retention in U.V. exposure.
Chain link fence is one of the oldest fencing materials but still very popular today. This chain link fence is a smart choice for both commercial and residential applications. chain link fence is not only one of the most economical materials, but also versatile.
Brief overview of chain link fences
Chain link fence, also known by some as a cyclone fence, is one of the most popular fencing options for light residential fencing to heavy commercial fencing and everything in between. chain link fence is one of the most practical fence styles, relatively easy to install, and very cost-effective. chain link fencing is a woven Chain link fencing is a woven fence made of coated mesh wire that is bent into a serrated shape so that it hooks together with the wire on either side. Chain link extends vertically to form a diamond pattern.
Importance and uses of Custom Chain Link Fence
Chain link fence is widely used in both residential and commercial premises. chain link fence is usually used for the following purposes:
Restriction of people/animals: in residential areas, chain link fence is often used as a boundary line to confine pets and children to a designated area.
Feeling of security: chain link fence does not block anything in the line of sight. It provides businesses and homeowners with a sense of security and extra protection for their property.
SECURITY: Whether it is a residential or commercial property, a chain link fence prevents intruders from entering your property. Barbed wire at the top of the fence or other additional security measures can further increase the security of the fence.
Sports Stadiums: baseball fields and other types of sports stadiums use chain link fences to mark players, fans, and stadium boundaries, as well as to increase the height of the stadium to keep out-of-bounds balls inside.
Schools: Schools use chain link fences to protect playgrounds and other outdoor areas.
High Security Zones: High security zones use a variety of devices to protect their buildings/facilities, including chain link fences that help deter intruders and trespassers.
Benefits of using chain link fences[Link to: What Is Chain Link Fence]
Chain link fences have many advantages over traditional fences such as wood or iron fences - they may save you money compared to other fences, they are strong and durable, and they come in a variety of styles. Chain link fences are easy to install and repair, and homeowners can save a lot of money on a new fence by installing or repairing it themselves. This type of fence is inexpensive and more homeowners can afford it. Best of all, chain link fences are strong and durable. They have an average lifespan of about 20 years, which is slightly shorter than a PVC or vinyl fence, but about the same as a quality wood fence. Chain link fences can be used in a variety of environments - from industrial to residential. These fences are available in a variety of styles and colors, so they can be fine-tuned to meet your specific needs!
EASY TO INSTALL: Need a fence that is quick and easy to install? chain link fence can be installed faster than most other types of fencing and at a fraction of the cost.
Affordability: price is usually the first factor we consider in our purchasing decisions. chain link fence is one of the cheapest options to install on your property. Even with a limited budget, chain link fence is never more expensive than you can afford.
Versatility: chain link fence can be customized to meet your specific needs, including different heights, sizes and color coatings. The ease with which chain link fence can be customized ensures that it can be used for many different applications.
Visibility: chain link fence is 100% transparent. Visibility continues to be one of its biggest advantages as you can see people approaching the area, receiving sunlight, and enjoying more freedom than with traditional fences.
DURABILITY: CHAIN LINK FENCE is made of interlocking coated steel wires, making it one of the strongest and most durable fencing materials available. It is not susceptible to weather damage and is easy to maintain after installation.
LOW MAINTENANCE: Once installed, chain link fence is self-maintaining. Whether you choose galvanized, vinyl or aluminized coating, it will not rust or break down. Mow your lawn and everything is ready to go!
Versatile: Design the chain link fence to your specifications, whether it's waist-high or 20 feet high, topped with wire mesh or otherwise customized. You control every aspect of your chain link fence design.
Chain Link Fences History
While no one can be 100% certain of the true origins of chain link fence, most sources claim that the first commercial production of barbed wire fencing came from the same place and time. All arrows point to Barnard, Bishop and Barnard in 1844, a company based in England with a history of hardware and garment manufacturing, which is technically perfectly plausible once you learn about the machines used to make barbed wire fencing, but more on that later.
How is a chain link fence made?
Now we've got some background knowledge, but how is a wire fence made? The answer is simple, it's made by machine, but we won't keep it short and sweet here, so we'll break down the technical process into a few steps so you can understand it better.
Huge spools of wire are transported through the factory to reach the production floor.
The wires are then fed into machines to be straightened.
At this stage, it is usually coated with thermoplastic and cooled in a liquid to solidify said plastic.
Once the coating is complete, the wire is wound onto the spool again for transportation.
The wire must now be transported to the "braiding shop" where it is made into fencing.
Once on the floor, the wires are semi-helicalized to form a kind of coil.
The coils of wire cascade upwards to form what we know as a connecting fence.
Once large pieces of fence are formed, they are cut and sold for use!
Chain Link Fence Fabric Coating Process
Chain link fence consists of spirals woven together to form a diamond pattern. Chain link fences are available in a variety of sizes and specifications. Chain link fabrics have three types of coatings:
1. extruded
Most residential areas use extrudedchain link fence. the process applies a thick polymer coating to the wire as an inexpensive way to add color and protection. The fabric is then woven with wire to achieve the desired mesh size and height.
2. Extrusion and bonding
The extrusion and bonding process uses polyvinyl chloride (PVC), which is applied by pressure to a wire coated with an adhesive. Using this method strengthens the wire and prevents spalling or cracking. Black chain link fencing in this fabric is ideal for commercial applications.
3. Fusing and Bonding
The fusion bonding process uses heat to fuse PVC to the wire to provide better protection and add color. Compared to extrusion bonding, fusion bonded wire has a thin PVC coating that provides greater resistance to spalling. This chain link fence is typically used in industrial applications and is more costly.
Galvanized Chain Link Fence is a fence made of woven galvanized steel wire, usually coated with zinc.
Features and Benefits
Prevents rust and corrosion
Improves durability
Scratch resistance
Durability
Corrosion resistance
Color-Coated Chain Link Fencing
Want to buy chain link fencing in a variety of different colors?Color-Coated Chain Link Fencing is made by coating metal chain link fence wires with colored PVC or vinyl. This not only provides the benefits of PVC coated chain link fencing - extra durability - but also adds to the aesthetic value of the fence. Color coated link fencing is available in a variety of colors including black, red, gray, brown, beige, green, white and more.
Black Chain Link Fence
Black Chain Link Fence are some of the most affordable and popular fence styles available. These fences provide security and privacy, blend well with the landscape, and control access to the property. Contractors can customize black chain link fences because the material is extremely versatile.
Black chain link fencing is a woven fence with a vinyl coating that gives it its color. The vinyl coating helps prevent corrosion and extends the life of the fence. Black vinyl coated chain link fences are becoming increasingly popular due to their cost-effective design and low maintenance costs.
Installation tips and uses
They have practical applications in houses, schools, parks, and commercial and industrial businesses. These fences are available in a variety of gauges, mesh sizes and heights. Black Chain Link Fence Meets or Exceeds American Society for Testing and Materials (ATSM) Standards
Green Chain Link Fence Systems
Chain link fences are made from green PVC coated steel wire, woven into a zig zag pattern to create the familiar and popular diamond shaped fence. This type of fence is available commonly in heights varying between three and twelve feet.
Features and aesthetic appeal
Installation tips and uses[Link to: Green Chain Link Fence Systems]
Choose right type chain link fences
The best type of chain link fence is the one that will meet your needs. If you need a fence for industrial use, then a sturdy galvanized metal chain link fence is the best choice. However, if you are looking for something more aesthetically pleasing for commercial or residential use, then consider a PVC coated or color coated chain link fence. They are available in a wide range of colors. If privacy is your priority, then slat chain link fencing is the best option. Also ask your fencing company for their recommendations and they will advise you according to your preferences and needs.
Most people think of galvanized chain link fencing when they think of chain link fabric. It is a traditional metal chain link mesh fence made of steel wires twisted together to look like diamonds. It is made of high-quality steel with a hot-dipped galvanized coating to prevent rust and corrosion. This chain link fence is perfect for homeowners on a budget who need a simple and affordable solution to mark their property lines or keep small children and pets in the yard while maintaining a view. Galvanized chain link fences are also used in situations where safety is a priority.
PVC coated chain link fences offer superior appearance and durability over traditional galvanized chain link fences. This type of fence is made by adding a thin layer of PVC or black vinyl coating around the wire strands. Covering chain link fencing with a PVC coating actually makes the fence more resistant to corrosion and weathering - making it a great choice for outdoor use, especially in wet areas.The PVC coating also makes it ideal for chain link fencing in residential areas. The coating downplays the metallic look of the fence, making it look less industrial and more homey. Keep in mind that the top and bottom crossbars, as well as the fence posts, are usually made of steel. However, if you want the fence to blend in better with other residential fences, you can swap them out for other materials such as wood.
The main reason why hook and loop fencing is so popular is due to its relatively low cost and ease of installation. A handy person can install a chain link fence on their own without too much hassle, simply by using a how-to guide, and without hiring a professional fencer. Typically, concrete and angle iron are the posts used with chain link, but wood posts can also be used if preferred. It's also a clear style fence that won't block sunlight, and the open style makes it ideal for particularly windy and exposed areas
Step-by-step guide to installation
1. Measurement and sampling: according to the design requirements of the drawings and the actual terrain, features of the situation for construction sampling, set out the center line of the column, according to the specified slope and linear installation of isolation fence.
2. The original ground treatment is to ensure that the guardrail installation line smooth and solid overall important prerequisite. Must be under the foundation of the soft layer of replacement and tamping treatment, before the column can be buried to ensure that the column is firm. Column installation is carried out in sections, from the longitudinal point of view, the axis of the column in a straight line, there should not be uneven phenomenon; from the height point of view, the top of the column is smooth, there should be no unevenness of the situation, except for special terrain.
3. According to the measurement of sampling, set up markers and white lines, fill the original surface of the excavation and slope, and again tamping, installation of sampling location of the excavation of the column pit, to ensure that the size of the pit.
4. The installation of columns must ensure that the columns of the installation process, as well as the foundation of the connection is tight, column installation process should be a small line on the installation of columns straightness testing, local adjustments to ensure that the straight section of the straight section of the curve section of the rounded section, the columns fixed in accordance with the requirements of the design drawings.
5. The mesh must be firmly connected with the column, and the mesh surface should be installed smoothly, without obvious warping and bumpy phenomenon.
6. After temporary positioning and installation of columns, install the railings, and then pour the concrete foundation and timely maintenance after ensuring correct and firm installation.
Tools and materials needed[Link to: Chain Link Fence Installation]
Chain Link Fence Components
Detailed look at essential components
Chain link fencing consists of four main components:
Frame: the most important component of chain link fencing is the frame. It consists of steel tubing that is used as uprights to form the frame from which the wire mesh is suspended. The posts are placed into the ground and filled with concrete to hold the mesh in place.
Mesh: Wire mesh fabric is bent and interconnected to form a flexible but strong fence. Different sizes of wire provide barriers for homes, schools and other locations. Most mesh fabrics have a galvanized coating on top for added corrosion resistance.
ACCESSORIES: Accessories provide a sturdy barrier for fencing. These include top caps located at the top of the posts and crossbars that hold the bottom crossbars in place. Tension bands hold the mesh fabric together and prevent it from moving away from the supports.
GATE: Chain link fences require some type of gate. This may be a hinged passable gate, or a long, supported gate for automobile traffic, or some other type of gate.
Chain Link Fence Cost
Factors affecting the cost
On average, the cost of fencing materials ranges from $5 to $20 per foot and installation costs range from $10 to $20 per linear foot.Home Advisor reports that the national average cost to install a chain link fence is $2,156.
An additional $5,000 would be required if the fence were six feet or more in height. Thicker wire and upgraded materials would also increase the price of the fence. In this case, expect to pay as much as $40 per linear foot of height, plus an additional 25 to 50 percent of the total cost for installation.
Chain Link Fence Price
Average price ranges
New chain link fencing, including parts and installation, averages $10 to $17 per linear foot.PVC coated chain link fencing will cost slightly more. The cost per linear foot is $13 to $20. The average cost of chain link fencing is $1,200. However, depending on the additions to a traditional metal chain link fence, it may be slightly more expensive.
How to Repair a Chain Link Fence
If the damage to your barbed wire fence originates from a damaged mesh section, replacing it is simple. Here are the steps you need to follow.
Step 1. Remove Damaged Chain Link Fabric
First, determine exactly where the damaged fabric of the chain link fence begins and ends. This will tell you how much needs to be removed and replaced. Once you have determined the extent of the damaged section, mark the fence. Then use wire cutters to unravel the wire from where it connects to the pipe at the top of the fence.
Next, locate the end of the damaged portion of the mesh and untangle the wire from its neighboring portion as well as the top and bottom of the fence. Save the wires as you untangle them. Once the wires have been untangled (by circling around the damaged portion of the fence), this portion of the mesh can be removed.
Step 2: Size the Replacement Fabric
Correctly size the replacement section so that it can be installed correctly. You can place the removed damaged section on top of the replacement fabric so you know how much is needed. However, you may want to leave at least one or two additional connections on the replacement section to ensure there is enough room to attach it to the ends of the existing fence.
Once you've measured how much replacement netting you'll need, use pliers to undo the wire holding it to the replacement fence roll.
Step 3. Weave the new fabric into place
Finally, weave the fabric into the holes in the fence. Use wire ties to loosely hang the replacement fabric in the space so that it is properly positioned. Then remove the wires you removed in step one and weave the sections back together.
Once you have completed this step, you have successfully repaired the mesh portion of the fence.
Qunkun Chain Link Fence materials meet new strength and quality standards to assure lasting beauty and your continued satisfaction for many years to come.
Chain Link Fence has protected children and pets in the backyards and schoolyards of since the turn of the century. It is known for its tradition of value, durability and strength. While now available in color-coated varieties, homeowners should recognize the value of traditional chain-link fence as it remains more affordable, highly dependable and America’s number one selling fence system.
The average consumer expects a new chain-link fence to last over 20 years and one built with quality materials can last even longer. To get the enjoyment and durability you expect from your new fence, invest in quality materials. A chain link fence built with quality materials can last longer than the 20 years expected by most consumers, and far longer than wood and some other fence products.
Chain Link Fencing can be used as breeding protection nets, coal mine protection nets, stadium protection nets, stadium fence nets, training field protection nets, slope protection, greening fences, rivers, buildings, security protection of residential quarters, workshop/warehouse isolation, etc.
Easy to install: chain link fencing is simple and straightforward to install, which means that our team of skilled fencing contractors can get the job done quickly and fix the problem for you right away.
LOW MAINTENANCE: Unlike other types of fencing, chain link fences require little to no maintenance and can last for years without showing any signs of damage. The galvanized metal on chain link fences is rust-resistant and pests such as termites will not affect the metal.
EFFECTIVE: Chain link fences are very effective at protecting children and keeping pets in the yard without completely blocking the view out of the yard.
MULTIPLE APPEARANCE OPTIONS: Chain link fences are now available in a variety of styles, so you can choose the one that's right for your yard. You can choose from standard silver steel or color-coated fencing, as well as the thickness and style of the fencing material
Upgrade your property with a durable chain link fence from Wholesale Fence. Our high-quality chain link fencing offers durability, security, and low maintenance. Our chain link fences are made from premium materials that can withstand harsh weather conditions and resist corrosion. They provide a secure barrier against unauthorized access for commercial, industrial or residential properties. As a trusted supplier of competitively priced fencing, Wholesale Fence offers color-coated chain link, chain link security fencing, vinyl slat chain link, and galvanized chain link options. Upgrade your property today with our reliable and durable chain link fencing. Contact us for a quote
Bulk Chain Link Fence
Chain link fence sales manufacturer and wholesale pricing material supply company, supplying chain link fencing, vinyl, aluminum, decorative and cedar wood fencing , our heavy-duty, American-made materials offer unmatched strength and durability, leaving you high and dry while enhancing the security and beauty of your property. Our discounted pricing and volume buying capabilities ensure that contractors, distributors and homeowners enjoy significant savings while obtaining top-notch materials for their projects.
Custom Chain Link Fence
Custom chain link is a very affordable option that is durable and can withstand almost any type of inclement weather. Chain link is also ideal for keeping pets and children safe in your yard!
Customization options
color
coating
gauge
hight
length
How Chain Link Fence Is Made and Manufactured
a) feeding the wire roll into the feeding mechanism of the chain link machine where the mesh is made;
b) passing the wire through the forming machine where the required height, shape and opening of the mesh are formed so that the wire can be woven with the mesh being formed;
c) introducing the newly formed wire into the worm and blade mechanism so that the wire can be woven with the mesh being made;
d) pushing the mesh towards the twisting and/or bending mechanism to keep the mesh taut so that it can be advanced when released by the rolling mechanism;
e) compacting the mesh being rolled and, at the beginning of this stage, securing to the mesh an extension system which will wrap around the mesh being formed to facilitate future unrolling by the user; and f) securing the newly compacted mesh with a cable tie to keep it compacted.
